BMW Exhaust Camshaft Problem
“Something’s not quite right with it.”
That was the concern raised by Mrs L, who runs a local used-car dealership.
A BMW 118i had been returned shortly after sale, with the customer reporting uneven idle behaviour and recurring BMW engine warning light messages. Initial checks carried out by the used-car dealership hadn’t explained the issue.
With no clear cause of the BMW 118i rough idle problem, the vehicle was brought to our BMW specialists at Fitch Autos, Brownhills, for a more detailed assessment.
While the symptoms were clear, identifying the root cause required a structured diagnostic process. That approach allowed our team to uncover a BMW exhaust camshaft problem that was disrupting correct engine timing during the first visit.
Discover how our experts traced the fault, identified the cause, and carried out the repair that restored smooth, reliable running.
Assessing the BMW 118i After Reports of Rough Idle
When the BMW 118i arrived at Fitch Autos, Brownhills, our technicians began by listening to what Mrs L and her customer had been experiencing. We then confirmed the symptoms through a structured assessment.
Mrs L stated that the BMW had been showing a BMW engine warning light, idling unevenly, and occasionally displaying a drivetrain malfunction message. However, earlier checks carried out by her used-car dealership hadn’t uncovered the cause, so the aim was to establish what the vehicle’s systems were indicating.
Based on this information, our initial assessment included:
- A visual check under the bonnet to look for disturbed components or evidence of recent work.
- A full system scan using BMW manufacturer data to identify stored or active fault codes.
- A controlled engine start to observe idle behaviour and overall engine operation.
The visual checks our team performed didn’t reveal an obvious cause, so we conducted a fault code scan.
Two fault codes were identified that were directly related to the reported issues:
- 130304 – VANOS exhaust cam jammed
- 160021 – Crankshaft sensor loss of synchronisation
(VANOS is BMW’s name for its variable valve timing system, which adjusts camshaft positioning to support efficient engine operation.)
Together, these results showed three important points:
- The engine control unit had detected a fault affecting exhaust camshaft control and VANOS function.
- Synchronisation between the crankshaft and camshaft had been lost.
- The BMW 118i rough idle and BMW engine warning light were linked, not separate issues.
Although the fault codes aligned with the vehicle’s symptoms, additional testing was needed to identify the root cause of the BMW exhaust camshaft problem.
Pinpointing the Cause of the BMW 118i Timing Fault
Once the initial assessments confirmed VANOS-related and synchronisation faults, our attention turned to the BMW 118i engine timing system. Several components influence timing accuracy, so a structured diagnostic approach was essential.
Guided by BMW technical data and testing routines, our technicians followed a methodical plan:
- Electronically assess engine timing using an oscilloscope to compare crankshaft and camshaft signals.
- Remove the rocker cover and related components to allow physical inspection of the timing system.
- Examine the VANOS components to determine whether the issue involves the control valves, the pulley mechanism, or the camshaft itself.
The oscilloscope results marked a turning point in our investigation. The signal patterns indicated incorrect exhaust camshaft timing, ruling out a sensor-only issue and prompting us to focus on a mechanical inspection.
To verify this, the rocker cover and high-pressure fuel injectors were removed, allowing full access to the camshaft and timing assembly. This also enabled accurate physical timing checks.
Both electronic testing and mechanical measurement led to the same outcome:
The exhaust camshaft wasn’t reaching the correct position relative to the crankshaft.
Further checks then focused on the systems that adjust and monitor exhaust camshaft timing.
Two connected faults were identified:
- A fault within the exhaust camshaft timing adjustment system that prevented correct camshaft positioning.
- An issue affecting how the exhaust camshaft position reference was being interpreted.
As a result, the engine control unit couldn’t consistently match the requested camshaft position with its actual position. This caused incorrect valve timing, most noticeable at idle, leading to the BMW engine warning light, unstable running, and the drivetrain malfunction message.
With the BMW exhaust camshaft problem confirmed, our experts turned to repairing the vehicle and restoring the correct camshaft timing and engine operation.
Carrying Out Repairs for the BMW Exhaust Camshaft Issue
Once the cause of the BMW exhaust camshaft problem had been established, our BMW technicians called Mrs L to explain the findings clearly and discuss what would be required to restore the vehicle’s exhaust camshaft timing.
This gave her a clear understanding of what was behind the issue and what work would be required to put it right.
At Fitch Autos, Brownhills, no work proceeds until everything has been fully explained and agreed. This ensures you remain in the know and in complete control throughout the repair process.
After reviewing the findings with our BMW experts, Mrs L approved the recommended repairs and confirmed we could begin working on the vehicle.
With approval in place, our team sourced high-quality BMW replacement components and began the repair, following BMW’s repair procedures at each stage.
The repair was completed in the following stages:
1. Removing the affected timing components
To access the faulty parts, the upper engine components were removed in accordance with BMW repair guidance. This allowed safe access to the exhaust camshaft timing components, preparing the engine for repair.
2. Installing the replacement exhaust camshaft and timing components
The replacement exhaust camshaft and associated timing parts were installed in accordance with BMW manufacturer procedures. This ensured accurate positioning and dependable operation once reassembled.
3. Renewing supporting timing-control components
Related timing-control components, including elements of the VANOS system, were renewed as part of the repair to support reliable camshaft operation after reassembly.
4. Setting and confirming engine timing using BMW timing tools
With the new components in place, engine timing was set and verified to confirm the camshaft and crankshaft were correctly synchronised as specified by BMW.
5. Final Engine Reassembly
Once timing had been confirmed, our technicians carried out full engine reassembly, following BMW procedures to ensure all components were refitted correctly and securely.
With reassembly complete, the BMW 118i was ready to move into the final stage of the repair process – Confirming the repair was successful.
Final Checks After Repairing the BMW Camshaft Fault
Once repairs were complete, our BMW technicians conducted a series of checks to confirm the camshaft timing issue had been fully resolved and that the engine was operating correctly.
As part of this final verification process, our BMW experts:
- Confirmed camshaft and crankshaft timing after reassembly.
- Ran system checks to verify no related fault codes remained.
- Monitored engine behaviour at idle and during a controlled road test.
These checks showed that exhaust camshaft timing had been corrected, the BMW 118i rough idle had been resolved, and the drivetrain malfunction message no longer appeared.
Following the final checks, we contacted Mrs L to confirm the outcome. She was pleased with the work carried out and felt assured the vehicle was back to top working condition.
The BMW left Fitch Autos, Brownhills, running smoothly, with no further BMW exhaust camshaft problem or BMW engine warning lights present.
